Apply Materials only to Pipes or Tubes from an Assembly
修改于: 六月 20,2015
评级:
下载: 281
评论:

规格

下载:281
说明:When routing, sometimes we forget to apply material from the master pipe/tube. This macro save lot of time, automatically applying a selected material e.x. AISI 304 to all pipes or tubes part. This macro must be edited with user Library path, and material preference, first.
    先决条件： An assembly is Open. It should content several Pipe/Tube assemblies with different components on them.
  后决条件： A predefined material "AISI 304" overwrites the current material. It must be set up with user Library route, before running the Macro.
SOLIDWORKS 版本：{0} 2014
编程语言: SW_VBA




宏可能包含病毒或其它安全危害。SOLIDWORKS Corporation 没有验证此站点中张贴的宏可安全使用且来自可信源处。

下载 SOLIDWORKS 宏。



（需要登录）
